Pin definition:
- VCC: 3.3-5V
- GND: Ground
- SCL: Serial Clock
- SDA: Serial Data Feature:
- Size: 0.96 inch
- Resolution: 128*64
- Color: white, blue (optional)
- Viewing angle: >160°
- Support platform: 51 series, MSP430 series, STM32/2, etc.
- Ultra low power consumption: 0.04W during normal operation
- Wide voltage support: DC 3.3V-5V
- Working temperature: -30 ° C ~ 80 ° C
- Driver chip: SSD1306
- Communication method: IIC, only 2 I/O ports
- Backlight: OLED self-illumination, no backlight required Package includes:1 x OLED module
Supports many control chip: Fully compatible with Arduino, 51 Series, MSP430 Series, STM32 / 2, CSR IC, etc.
High resolution: 128 x 64
Pin Definition: GND, VCC ,SCL, SDA
Working Temperature: -30 ℃ ~ 70 ℃.(Your satisfaction is our unremitting pursuit,If you have any questions, please feel free to contact us.)
